| Product name | titanium welding wire |
| Standard | AWS A5.16, ASTM B863, ASTM F136, ASTM F67 |
| Grade | Gr. 1, Gr. 2, Gr. 5, Gr 7, Gr. 9, Gr. 12, Gr. 23 |
| Dimension(mm) | Dia. 0.8-6.0 * Coil / Straight / Spool |
| Certificate | ISO 9001:2008 |
| Surface | Acide Washing ,Polished |
| Product Names | Grade | Dimensions(mm) | Coil | Straight |
| PureTitanium wire | GR1,GR2 | 0.8 to 2.0 | √ | × |
| >2.0 to 6.0 | √ | √ | ||
| Titanium alloy wire | GR5,GR7,GR9 | 1.0 to 6.0 | √ | √ |
| Titanium welding wire | GR1,GR2,GR3,GR7,GR9,GR12,GR23 | 0.8 to 6.0 | √ | √ |
China titanium straight wire Manufacturer Factory Supplier
Common Size
| Designation | standard | In coil Size(mm) | Straight(mm) | Length of straight |
| ERTi-1, ERTi-2,ERTi-5,ERTi-5Eli,ERTi-7,ERTi-9 Eli |
AWS 5.16 |
0.5—6.0 |
1.0—6.0 |
MAX 1000mm |
|
Gr1, Gr2, Gr5, Gr7, Gr9, Gr12, Gr23, |
ASTMB863, ASTM B348, JISH4670, DIN17864, |
0.078—5.0 | 1.0---6.0 |
MAX 1000mm |
China titanium spool wire Manufacturer Factory Supplier
|
Some more informations about Titanium Wires
|
||||
|
Finish Type
|
Available Shapes
|
Minimum Diameter
|
Diameter Tolerance
|
Price Leval
|
|
Acid Washed
|
Coil or Straight
|
0.2mm
|
Normal
|
Lower
|
|
Polished
|
Coil or Straight
|
0.2mm
|
Normal
|
Medium
|
|
Grinding Polished
|
Only Straight
|
0.8mm
|
Accurate and can be very small
|
Higher
|
Notes
Grinding Polished titanium wire is grinded by Grinding Machine,it needs cutted to special length at first and then straightened,and then grinding it to demanded diameter,it generates wastes of material and additional grinding fees,so price is higher.
But diameter tolerance can be controled to be very accurate and even much smaller like 0.005mm.
China titanium straight wire Manufacturer Factory Supplier
Production Process
