| Product name | Titanium sheet metal |
| Standard |
ASTM B265,ASME SB265,AMS 4911,ASTM F67,ASTM F136 ISO5832-2,ISO5832-3 |
| Thickness | 0.3-60mm |
| Width | ≤3,000mm |
| Length | ≤12,000mm |
| Grade | Gr1, Gr2, Gr5, Gr7, Gr9, Gr10, Gr12, Gr23, etc. |
| Special |
T(4.0-60.0) × W(100-3000) × L(1000-12000)mm T(0.3- 4.0) × W(100-1000) × L(1000-12000)mm |
| Features |
1.high corrosion resistance 2.low density 3.non-ferromagnetic 4.good biocompatibility |
| The specification can be changed by the customers' requirements. | |
Titanium sheet metal US standard: GR1, GR2, GR3, GR5, GR7, GR12
Titanium sheet metal Russian signs: BT1-00, BT1-0, BT1-2 and so on
Titanium sheet metal CHINA brands: TA1, TA2, TA3, TA5, TA6, TA7, TA9, TA10, TB2, TC1, TC2, TC3, TC4
Titanium sheet metal manufacturing process
A forging process carried out at a metal recrystallization temperature.
Hot rolling is carried out at a temperature higher than the recrystallization temperature.
Cold rolling plastic deformation temperature is lower than the recovery temperature of the rolling process.
An organic heat treatment process in which the metal is slowly heated to a certain temperature, maintained for a sufficient time, and then cooled at a suitable rate (usually slow cooling, sometimes controlled cooling).
Pickling: The part is immersed in an aqueous solution of sulfuric acid or the like to remove a thin film such as an oxide on the metal surface. Is electroplating, enamel, rolling and other pre-treatment or intermediate processing
titanium sheet metal characteristics
1. titanium sheet metal is the surface of the oxide film is equivalent to a good long-term wear-resistant release agent, the use of titanium sheet metal to save the separation agent, so that easy to peel off the plate, eliminating the pre-treatment process, The board is lighter than the copper plate.
2. titanium sheet metal life is more than 3 times the copper plate, according to operating conditions up to 10 to 20 years
3. With titanium sheet metal made of electrolytic copper crystal structure dense, smooth surface, excellent quality.
4. Since the titanium sheet metal without the need to apply the separation agent, which can avoid the pollution of copper electrolyte.
5. To improve production capacity to reduce the cost of electrolytic copper production, which has a better economic benefits.
